PETRA

PORCELÁNICOS – COLECCIÓN PETRA

logo antipatogeno - Petra
ico Antideslizante clase 3 fnd blanco - Petra

Non-slip class 3/ Smooth class 1

Inspired by the purity of the most genuine stones, that is how Petra porcelain tile collection is born. Three colours that evoke the original tones of traditional stone, giving the versatility that the most modern spaces need. Suitable for both for inside (smooth finishing) and outside (anti-slip finishing). Thanks to its multi-format bases, its placement can be modular creating more innovative spaces. It has all the special ceramic pieces to provide a solution to all kind of architectural challenges. The large ceramic steps (120 cm) provide elegance and continuity to the stairs of the different spaces. Its extensive range of special pieces for pools allow aesthetic uniformity from the inside to the outside of the home.

fnd espacio gris der - Petra

Colours

60x60 OCRE - Petra

Ocre

60X60 PETRA BEIGE - Petra

Beige

60X60 PETRA GRIS - Petra

Grey

Sizes

form 30x30 1 - Petra

30X30

form 30x60 1 - Petra

30X60

form 60x60 1 - Petra

60X60

form 60x120 2 - Petra

60X120

fnd espacio gris izq - Petra

Special pieces

All finishing pieces are available in all indicated colours

petra colores - Petra
petra colores - Petra

PELDAÑO REDONDEADO 30 - Petra

PELDAÑO REDONDEADO 30 (Liso)

peldano redondeado 120 - Petra

ROUNDED STEP TREAD 120 (SMOOTH)

* Disponible 150/180 bajo pedido

peldano recto 600 - Petra

STRAIGHT STEP TREAD 60 (ANTI SLIP)

peldano recto 120 - Petra

STRAIGHT STEP TREAD 120 (ANTI SLIP / SMOOTH)

"Available 180 by request."

peldano recto 120 - Petra

STRAIGHT STEP TREAD 150 (ANTI-SLIP)

tapa peldano redonda der - Petra

RIGHT ROUNDED TREAD COVER

tapa peldano redonda izq - Petra

LEFT ROUNDED TREAD COVER

tapa peldano recta - Petra

STRAIGHT TREAD COVER

zanquin recto izq - Petra

LEFT STRAIGHT STRINGER

zanquin recto der - Petra

RIGHT STRAIGHT STRINGER

zanquin redondo izq - Petra

LEFT ROUNDED STRINGER

zanquin redondo der - Petra

RIGHT ROUNDED STRINGER

rodapie 3d - Petra

SKIRTING BOARD 40

esquina redondeada - Petra

ROUNDED CORNER

tabica 15x20 1 - Petra

RISER 15X120

tabica 15x20 1 - Petra

RISER 15X150

Finishing pieces for pools

borde desbordante 60 - Petra

OVERFLOW EDGE 60

ESQ. INT. BORDE DESBORDANTE - Petra

OVERFLOW INSIDE EDGE

ESQ EXT BORDE DESBORDANTE - Petra

OVERFLOW OUTSIDE EDGE

REJILLA MONOCOMPACT RANURADA - Petra

MONOCOMPACT GROOVED GRID

Esquina rej2 - Petra

CORNER GRID

rejilla flexible ranurada - Petra

GROOVED FLEXIBLE GRID

rejilla oculta - Petra

HIDDEN CERAMIC GRID

canaleta - Petra

OVERFLOW CHANNEL

cantonera - Petra

EXTERNAL RADIAL TILE

rinconera - Petra

INTERNAL RADIAL TILE

peldano recto 600 - Petra

STRAIGHT STAIR-TREAD 60

peldano recto 120 - Petra

STRAIGHT STAIR-TREAD 120

ESCOCIA CANTONERA EXTERIOR - Petra

ROUND EXTERNAL MITRE

ESCOCIA RINCONERA INTERIOR - Petra

ROUND INTERNAL MITRE

ESQ. INT.RINCONERA - Petra

INTERNAL MITRE

esquina ext cantonera - Petra

EXTERNAL MITRE

rinconera transicion - Petra

INTERNAL RADIAL TRANSITION TILE

cantonera transicion - Petra

EXTERNAL RADIAL TRANSITION TILE

SILUETA NG - Petra

MONOCOMPACT EDGE 120

fnd espacio gris der - Petra

Technical features

Porcelain
Porcelain

Glazed
Glazed

ico reacciona al fuego - Petra
Reacciona al fuego

A1 does not react to fire

Dimension tolerance
Dimension tolerance

<1% / <0,6%
máx 2 mm

Water absorption
Water absorption

E≤0,5%

Linear thermal expansion coefficient
Linear thermal expansion coefficient

5,8×10-6x C-1

Breaking strength
Breaking strength

>40N/mm2

Resistance to surface abrasion
Resistance to surface abrasion

PEI 4

Resistance to stains
Resistance to stains

class 5

Not required out of Spain
Not required out of Spain

Anti-slip class 3

Smooth class 1

Barefoot slip resistance
Barefoot slip resistance

Anti-slip C

Smooth A

Slip resistance with footwear
Slip resistance with footwear

Non-slip R11

Smooth R9

Crazing resistance
Crazing resistance

Yes

Frost resistance
Frost resistance

Resistance to thermal shock
Resistance to thermal shock

Chemical resistance
Chemical resistance

Shade varation
Shade varation

V2 ligero

Antibacterian
Anti-bacterial

R>2
Reducción
antibacteriana>99 %
